Calibration Charts			Case = STA34_C2AB ,  Cell  =  2B															06/01/05
								STA34 Cells 2A & 2B
Simulation Period			10/01/03	03/31/05				Cell 2B in SAV
Output Period:			10/01/03	03/31/05
Calibration Period:			04/01/04	03/31/05
Predicted Values for Calibration Period						Calibration Set:		SAV_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			39	cm		K	52.5	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			19%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			4.2	cm/d		C1	22	ppb		Count		16	16	16	14	14	14
Mean P Load			404	mg/m2-yr		C2	300	ppb		Observed		43.7	5.7	1.13	20.0	20.0	20.0	1.00
Mean Flow/Width			121	m2/day		Z1	40	cm		Predicted		46.5	8.6	1.30	15.1	9.4	9.3	0.62
Hydraulic Resid Time			9	days		Z2	100	cm		Mean Resid		-2.8	-3.0	-0.17	4.9	10.6	10.7	0.38
Inflow Conc			26	ppb		Z3	200	cm		Bias %		-6%	-34%	-13%	33%	113%	114%	61%
FWM Outflow Conc			13	ppb		Avg Int	7	days		Residual SE%		69%	112%	67%	96%	71%	71%
GeoMn Outflow Conc			7	ppb		Area	11.712	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
