Calibration Charts			Case = STA2_C3 ,  Cell  =  C3															06/01/05
								STA2 - Cell 3
Simulation Period			03/01/01	03/24/05
Output Period:			03/01/01	03/24/05
Calibration Period:			05/01/03	03/24/05
Predicted Values for Calibration Period						Calibration Set:		SAV_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			87	cm		K	52.5	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			5.1	cm/d		C1	22	ppb		Count		24	24	24	23	23	23
Mean P Load			2368	mg/m2-yr		C2	300	ppb		Observed		80.1	4.9	0.72	14.9	14.6	15.6	0.98
Mean Flow/Width			291	m2/day		Z1	40	cm		Predicted		87.4	5.0	1.15	23.1	14.9	12.8	0.65
Hydraulic Resid Time			17	days		Z2	100	cm		Mean Resid		-7.3	-0.1	-0.43	-8.2	-0.4	2.8	0.33
Inflow Conc			128	ppb		Z3	200	cm		Bias %		-8%	-2%	-37%	-36%	-2%	22%	52%
FWM Outflow Conc			23	ppb		Avg Int	30	days		Residual SE%		26%	26%	24%	943%	54%	54%
GeoMn Outflow Conc			15	ppb		Area	9.1911	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
