Calibration Charts			Case = STA1W_C13 ,  Cell  =  C1															06/01/05
								STA1W - Cell 1 & 3 ; inflows include measured seepage return
Simulation Period			08/01/94	03/31/05
Output Period:			01/01/00	03/31/05
Calibration Period:			07/01/00	08/31/04
Predicted Values for Calibration Period						Calibration Set:		EMG_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			59	cm		K	16.8	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			4.6	cm/d		C1	22	ppb		Count		51	51	51	51	51	51
Mean P Load			2347	mg/m2-yr		C2	300	ppb		Observed		66.3	4.6	2.66	57.9	50.2	53.2	0.87
Mean Flow/Width			210	m2/day		Z1	40	cm		Predicted		58.9	4.0	2.64	65.5	57.6	57.7	0.88
Hydraulic Resid Time			13	days		Z2	100	cm		Mean Resid		7.3	0.6	0.03	-7.6	-7.5	-4.5	-0.01
Inflow Conc			140	ppb		Z3	200	cm		Bias %		12%	14%	1%	-12%	-13%	-8%	-2%
FWM Outflow Conc			65	ppb		Avg Int	30	days		Residual SE%		22%	48%	48%	82%	38%	38%
GeoMn Outflow Conc			58	ppb		Area	6.03	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
