Calibration Charts			Case = ENRP_C24 ,  Cell  =  C4															06/01/05
								ENRP Cells 2 & 4 in Series
Simulation Period			08/01/94	12/31/98				Prior to STA1W Construction
Output Period:			08/01/94	12/31/98
Calibration Period:			01/01/97	12/31/98
Predicted Values for Calibration Period						Calibration Set:		SAV_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			66	cm		K	52.5	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			12.6	cm/d		C1	22	ppb		Count		25	25	25	25	25	25
Mean P Load			1899	mg/m2-yr		C2	300	ppb		Observed		62.8	11.2	1.92	17.2	16.6	16.4	0.97
Mean Flow/Width			215	m2/day		Z1	40	cm		Predicted		66.0	12.1	2.49	20.5	20.4	20.0	0.99
Hydraulic Resid Time			5	days		Z2	100	cm		Mean Resid		-3.2	-1.0	-0.58	-3.4	-3.8	-3.5	-0.02
Inflow Conc			41	ppb		Z3	200	cm		Bias %		-5%	-8%	-23%	-16%	-18%	-18%	-2%
FWM Outflow Conc			21	ppb		Avg Int	30	days		Residual SE%		12%	16%	16%	48%	36%	36%
GeoMn Outflow Conc			20	ppb		Area	1.45	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
