Calibration Charts			Case = STA1W_C3 ,  Cell  =  C3															05/31/05
								STA1W - Cell 3
Simulation Period			08/01/94	03/31/05				Measured Outflows = G251-G256+G308
Output Period:			01/01/00	03/31/05
Calibration Period:			07/01/00	08/31/04
Predicted Values for Calibration Period						Calibration Set:		EMG_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			48	cm		K	16.9	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			6.7	cm/d		C1	22	ppb		Count		51	51	51	47	47	47
Mean P Load			1413	mg/m2-yr		C2	300	ppb		Observed		46.2	4.9	2.00	40.3	32.9	31.7	0.82
Mean Flow/Width			206	m2/day		Z1	40	cm		Predicted		48.5	6.2	1.95	31.4	27.3	22.8	0.87
Hydraulic Resid Time			7	days		Z2	100	cm		Mean Resid		-2.3	-1.3	0.04	8.9	5.7	8.9	-0.05
Inflow Conc			58	ppb		Z3	400	cm		Bias %		-5%	-20%	2%	28%	21%	39%	-6%
FWM Outflow Conc			31	ppb		Avg Int	30	days		Residual SE%		26%	45%	45%	114%	42%	42%
GeoMn Outflow Conc			27	ppb		Area	4.15	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
