Calibration Charts			Case = ENRP_C2 ,  Cell  =  C2															05/31/05
								ENRP Cell 2
Simulation Period			08/01/94	12/31/98				Prior to STA1W construction
Output Period:			08/01/94	12/31/98
Calibration Period:			01/01/97	12/31/98
Predicted Values for Calibration Period						Calibration Set:		EMG_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			76	cm		K	16.9	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			5.4	cm/d		C1	22	ppb		Count		25	25	25	25	25	25
Mean P Load			1328	mg/m2-yr		C2	300	ppb		Observed		74.2	4.8	1.72	35.6	34.4	34.3	0.97
Mean Flow/Width			204	m2/day		Z1	40	cm		Predicted		76.4	4.8	1.97	41.1	40.8	40.4	0.99
Hydraulic Resid Time			14	days		Z2	100	cm		Mean Resid		-2.2	0.0	-0.26	-5.5	-6.4	-6.1	-0.02
Inflow Conc			68	ppb		Z3	400	cm		Bias %		-3%	1%	-13%	-13%	-16%	-15%	-3%
FWM Outflow Conc			41	ppb		Avg Int	30	days		Residual SE%		9%	11%	11%	32%	30%	30%
GeoMn Outflow Conc			41	ppb		Area	3.81	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
