Calibration Charts			Case = C111_WEST ,  Cell  =  Marsh															05/31/05
								C111 - Periphyton Area - West Transect - Inflows from E1/W1
Simulation Period			01/01/95	12/31/00
Output Period:			01/01/97	12/31/00
Calibration Period:			08/01/98	12/31/00
Predicted Values for Calibration Period						Calibration Set:		PSTA_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			13	cm		K	23.6	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			37%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			5.3	cm/d		C1	22	ppb		Count		17	24	24	24	24	24
Mean P Load			142	mg/m2-yr		C2	300	ppb		Observed		12.5	6.6	0.39	5.9	5.3	5.0	0.91
Mean Flow/Width			121	m2/day		Z1	0	cm		Predicted		12.0	6.4	0.41	6.5	5.4	5.1	0.84
Hydraulic Resid Time			2	days		Z2	100	cm		Mean Resid		0.6	0.3	-0.02	-0.6	-0.1	-0.1	0.07
Inflow Conc			7	ppb		Z3	400	cm		Bias %		5%	4%	-5%	-9%	-2%	-2%	8%
FWM Outflow Conc			6	ppb		Avg Int	30	days		Residual SE%		36%	#N/A	13%	40%	37%	37%
GeoMn Outflow Conc			5	ppb		Area	14.168	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
