Calibration Charts			Case = STA1W_C4T ,  Cell  =  C4															05/31/05
								STA1W - Cell 4
Simulation Period			08/01/94	03/31/05				Inflow = G254
Output Period:			08/01/94	03/31/05				Outflow = G309+G256
Calibration Period:			07/01/00	08/31/04
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			64	cm		K	74.4	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			17.5	cm/d		C1	22	ppb		Count		51	51	51	51	51	51
Mean P Load			7328	mg/m2-yr		C2	300	ppb		Observed		66.4	17.2	9.79	56.9	37.1	35.9	0.65
Mean Flow/Width			298	m2/day		Z1	40	cm		Predicted		63.7	16.9	10.10	59.6	39.6	37.7	0.66
Hydraulic Resid Time			4	days		Z2	0	cm		Mean Resid		2.8	0.3	-0.31	-2.7	-2.4	-1.9	-0.01
Inflow Conc			114	ppb		Z3	0	cm		Bias %		4%	2%	-3%	-5%	-6%	-5%	-2%
FWM Outflow Conc			60	ppb		Avg Int	30	days		Residual SE%		24%	16%	16%	196%	38%	38%
GeoMn Outflow Conc			40	ppb		Area	1.45	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
