Calibration Charts			Case = STA1W_C3 ,  Cell  =  C3															05/31/05
								STA1W - Cell 3
Simulation Period			08/01/94	03/31/05				Measured Outflows = G251-G256+G308
Output Period:			01/01/00	03/31/05
Calibration Period:			07/01/00	08/31/04
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			48	cm		K	6.4	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			6.7	cm/d		C1	22	ppb		Count		51	51	51	47	47	47
Mean P Load			1413	mg/m2-yr		C2	300	ppb		Observed		46.2	4.9	2.00	40.3	32.9	31.7	0.82
Mean Flow/Width			206	m2/day		Z1	40	cm		Predicted		48.5	6.2	2.59	41.6	37.1	33.1	0.89
Hydraulic Resid Time			7	days		Z2	0	cm		Mean Resid		-2.3	-1.3	-0.59	-1.3	-4.2	-1.4	-0.08
Inflow Conc			58	ppb		Z3	0	cm		Bias %		-5%	-20%	-23%	-3%	-11%	-4%	-9%
FWM Outflow Conc			42	ppb		Avg Int	30	days		Residual SE%		26%	45%	45%	119%	31%	31%
GeoMn Outflow Conc			37	ppb		Area	4.15	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
