Calibration Charts			Case = HARNEY ,  Cell  =  -															05/31/05
								compiled by burns & mcdonnell
Simulation Period			10/01/90	08/31/03
Output Period:			10/01/90	08/31/03
Calibration Period:			10/01/91	08/31/03
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			288	cm		K	1.9	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			17.6	cm/d		C1	150	ppb		Count		135	146	146	146	146	146
Mean P Load			5024	mg/m2-yr		C2	0	ppb		Observed		279.7	17.6	14.91	84.9	78.1	78.0	0.92
Mean Flow/Width			1135	m2/day		Z1	40	cm		Predicted		287.6	17.6	13.66	77.4	74.5	74.3	0.96
Hydraulic Resid Time			16	days		Z2	100	cm		Mean Resid		-7.9	-0.1	1.25	7.5	3.6	3.7	-0.04
Inflow Conc			78	ppb		Z3	350	cm		Bias %		-3%	0%	9%	10%	5%	5%	-4%
FWM Outflow Conc			77	ppb		Avg Int	30	days		Residual SE%		6%	4%	4%	35%	22%	22%
GeoMn Outflow Conc			74	ppb		Area	29.93	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
